2 Port HDMI Switcher w/ Automatic Priority Port Selector
Reviews
Be The First To Review This Product!
Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.
Save time and hassle by automatically switching between your HDMI audio/video sources, using the VS221HDQ 2-Port HDMI Auto Switcher. This easy-to-use HDMI switch ensures seamless transition while switching video sources, with EDID copy maintaining your video resolution.
Seamless Signal Selection
Ensure seamless transition while switching video sources, with EDID copy maintaining native resolution with support for 1080p. Video connection emulation ensures the settings on any connected computers are not disrupted while switching to a different video source.
Effortless Control
Save time by connecting two HDMI video source devices to your HDMI display instead of manually connecting individual cables. Mounting hardware is also included for a tidy, professional installation.
Versatile Switching Options
Enjoy hassle-free operation with three different switching modes:
Automatic port selection: Enables your most recently activated video source to be displayed automatically.
Priority port selection: Prioritizes input number two above input number one. If the video source connected to input number two is activated that source will be displayed.
Manual port selection: Enables you to manually select your HDMI source with easy-to-use front panel buttons.
(VS221HDQ)
Standard Consumer Warranty
Ensure seamless transition while switching video sources, with EDID copymaintaining native resolution with support for 1080p
Packaging Information
Package Width: 19.7 cm [7.8 in]
Shipping (Package) Weight: 853 g [30.1 oz]
Performance
Audio Specifications: 7.1 surround sound
Max Distance: 10 m / 33 ft
Maximum Digital Resolutions: 1920x1200 / 1080p
Supported Resolutions: 1920x1200
1920x1080 (1080p)
1280x720 (720p)
Physical Characteristics
Color: Black
Material: Aluminum and Plastic
Product Height: 2 cm [0.8 in]
Product Length: 15.6 cm [6.1 in]
Product Width: 65 mm [2.6 in]
Weight of Product: 290 g [10.2 oz]
Power
Input Current: 0.6 A
Input Voltage: 100 - 240 AC
Output Current: 1.5 A
Output Voltage: 12V DC
Plug Type: M
Power Consumption (In Watts): 18
Power Source: AC Adapter Included
What's in the Box
Included in Package: foot pad set : HDMI auto switch : instruction Manual : mounting kit : remote control : universal power adapter (NA, EU, UK, AU)
Packaging Information
Package Length: 29.4 cm [11.6 in]
Package Height: 72 mm [2.8 in]
Indicators
LED Indicators: Source #2 activated : Source #1 activated
Hardware
Rack-Mountable: Yes
Ports: 2
Cabling: HDMI
AV Output: HDMI
AV Input: HDMI
Audio: Yes
Environmental
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 0%~80%
Connector(s)
Connector B: HDMI (19 pin) Female
Connector A: HDMI (19 pin) Female
Model # | VS221HDQ |
Barcode # | 065030855020 |
Brand | STAR TECH |
Shipping Weight | 0.8500kg |
Shipping Width | 0.290m |
Shipping Height | 0.070m |
Shipping Length | 0.200m |
Shipping Cubic | 0.004060000m3 |
Type | AV Splitter/Switcher |
