Star Tech 10m Active DP Cable DisplayPort to DisplayPort M/M

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Star Tech 10m Active DP Cable DisplayPort to DisplayPort M/M

The DISPL10MA 10m Active DisplayPort® Cable features a built-in active signal booster for a connection distance of up to 30 feet (10m) between your DisplayPort-enabled devices - almost double the DisplayPort connection distance limitation of 16ft, with no signal loss.

This durable yet lightweight active DP cable features a thinner 32 AWG wire construction that allows for a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed.

The 10m cable offers a bandwidth of 10.8 Gbps with support for maximum resolutions up to WQXGA (2560×1600) and optional audio support. The cable is both HDCP and DPCP capable, which ensures that digitally protected content is displayed properly.

Please Note: This cable features unidirectional architecture which requires that the cable is installed in the correct direction. Please refer to the "source" and "display" labels on the DisplayPort connectors, in order to ensure that the display device (monitor, projector etc.) and the DisplayPort source are connected properly.

(DISPL10MA)

This item comes with a 24 months warranty

Physical Characteristics
Color: Black
Connector Style: Straight
Product Height: 1.2 cm [0.5 in]
Product Length: 10 m [32.8 ft]
Product Width: 20 mm [0.8 in]
Weight of Product: 452 g [16 oz]
Wire Gauge: 32 AWG

Prominence
Description CDW 75 - 1st Line: StarTech.com 10m Active DisplayPort Cable - DP to DP M/M

What's in the Box
Included in Package: 10m Active DisplayPort® Cable - M/M

Physical Characteristics
Cable Length: 10 m [32.8 ft]

Packaging Information
Shipping (Package) Weight: 466 g [16.4 oz]
Package Width: 25.5 cm [10 in]
Package Quantity: 1
Package Length: 33 cm [13 in]
Package Height: 40 mm [1.6 in]

Hardware
Number of Conductors: 19
Fire Rating: CMG Rated (General Purpose)
Connector Plating: Nickel
Cable Shield Material: Aluminum-Mylar Foil with Braid
Cable Jacket Material: PVC - Polyvinyl Chloride

Environmental
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Operating Temperature: 0°C to 45°C (32°F to 113°F)

Connector(s)
Connector B: DisplayPort (20 pin) Male
Connector A: DisplayPort (20 pin) Male Latching

Model # DISPL10MA
Barcode # 065030854221
Brand STAR TECH
Shipping Weight 0.4700kg
Shipping Width 0.330m
Shipping Height 0.040m
Shipping Length 0.260m
Shipping Cubic 0.003432000m3
Type DisplayPort Cable
