Star Tech DP to DP Multi Monitor Hub - 3-Port MST Daisy Chain Splitter

This MST hub lets you connect three monitors to your DisplayPort™ (DP) 1.2 equipped Windows® laptop or desktop.

Increase productivity with multiple screens

The newest generations of computers are more portable than ever, which often means that you’re left with fewer video outputs and smaller integrated screens. This MST hub solves both of these problems by letting you connect three additional displays to your computer, which makes multitasking much easier.

Connect to any display

With the MST hub, you can use DisplayPort video adapters and cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. This MST hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.

Configure your displays for any environment

Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display giving you the freedom to multitask and increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.

Enjoy amazing video quality, without draining system resources

MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming and medical imaging.

Note: When using a DisplayPort 1.1 video card the MSTDP123DP will act as splitter, automatically mirroring your video source across all displays. Resolution limitations apply.

The MSTDP123DP supports plug-and-play installation for a hassle-free setup

(MSTDP123DP)

This item comes with a 3 Years warranty

Performance
Maximum Cable Distance To Display: 2 m [6.6 ft]
Maximum Digital Resolutions: Up to 4K
Wide Screen Supported: Yes

Physical Characteristics
Cable Length: 19 cm [7.5 in]
Color: Black
Material: Plastic
Product Height: 2 cm [0.8 in]
Product Length: 20 cm [7.9 in]
Product Width: 78 mm [3.1 in]
Weight of Product: 99 g [3.5 oz]

Power
Center Tip Polarity: Positive
Input Current: 0.5 A
Input Voltage: 100 - 240 AC
Output Current: 3A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 15
Power Source: AC Adapter Included

Prominence
Description CDW 75 - 1st Line: StarTech.com 3-Port Multi Monitor Adapter, DisplayPort to Triple DP MST Hub

Software
OS Compatibility: Windows 10 (32/64)
Windows 8/8.1 (32/64)
Windows 7(32/64)

Special Notes / Requirements
Note: DisplayPort 1.2 with MST+HBR2 support from the GPU is required for independent display output

What's in the Box
Included in Package: 3-Port Multi Monitor DisplayPort™ MST Hub : Instruction Manual : Universal Power Adapter (NA/EU/UK/AUS)

Performance
Audio Specifications: DisplayPort - 5.1 Channel Audio

Packaging Information
Shipping (Package) Weight: 409 g [14.4 oz]
Package Width: 22.9 cm [9 in]
Package Length: 15.5 cm [6.1 in]
Package Height: 55 mm [2.2 in]

Hardware
Ports: 3
Chipset ID: MegaChips - STDP4320
AV Output: DisplayPort - 1.2
AV Input: DisplayPort - 1.2
Audio: Yes
Active or Passive Adapter: Active

Environmental
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Operating Temperature: 0°C to 45°C (32°F to 113°F)

Connector(s)
Connector B: DisplayPort (20 pin) Female Latching
Connector A: DisplayPort (20 pin) Male Latching

Model # MSTDP123DP
Barcode # 065030851886
Brand STAR TECH
Shipping Weight 0.4100kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.230m
Shipping Cubic 0.002208000m3
Type AV Splitter/Switcher
