Star Tech USB C to DisplayPort Adapter -USB Type-C to DP 1.4 Converter

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Star Tech USB C to DisplayPort Adapter -USB Type-C to DP 1.4 Converter

This USB-C™ to DisplayPort adapter enables you to output DP video and audio from the USB Type-C™ port on your laptop or other device. The DP 1.4 adapter works with USB-C devices that pass a DisplayPort (DP) video signal, such as your MacBook Pro, Chromebook™ or 2018 iPad Pro. This enables you to connect your DisplayPort display to your USB-C computer using a DisplayPort cable.

Ultra HD 4K & 8K Resolution

The adapter lets you harness the video capabilities that are built into your computer's USB Type-C connection, to deliver the astonishing quality of UHD to your 4K 60Hz display. This makes it easier for you to multitask while working on the most resource-demanding applications imaginable.

With this adapter, you can also achieve an output resolution of up to 7680x4320 at 30Hz, which is perfect for performing high-resolution tasks such as viewing 8K video. Plus, the DP 1.4 adapter is backward compatible with 1080p displays, which makes it a great accessory for home, office or other workspace applications while future-proofing for 8K implementation.

Ultimate Portability

This USB Type-C video adapter is highly portable with a small footprint and lightweight design that's easy to tuck into your laptop bag. The adapter is the perfect accessory for connecting your MacBook Pro or Dell XPS™ to a DisplayPort monitor or display in BYOD (Bring Your Own Device) applications at the office.

Hassle-Free Connection with USB Type-C

This adapter lets you utilize the versatile USB Type-C port on your portable device. USB Type-C is a reversible connector, so it doesn't matter which way you plug it in, the adapter will always work, saving you the hassle and embarrassment of adjusting your device when you're trying to deliver a presentation.


This item comes with a 3 Years warranty

Supported Resolutions: DisplayPort: 7680x4320 (8K) / 30Hz
Video Revision: DisplayPort 1.4
Wide Screen Supported: Yes

Physical Characteristics
Cable Length: 14 cm [5.5 in]
Color: Black
Product Height: 1.4 cm [0.6 in]
Product Length: 18 cm [7.1 in]
Product Width: 37 mm [1.5 in]
Weight of Product: 17 g [0.6 oz]

Description CDW 75 - 1st Line: USB C to DisplayPort Adapter - USB Type-C to DP 1.4 - 4K 60Hz

Special Notes / Requirements
System and Cable Requirements: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.

What's in the Box
Included in Package: USB-C to DisplayPort adapter

Maximum Cable Distance To Display: 2 m [6.6 ft]
Audio Specifications: DisplayPort - 7.1 Channel Audio

Packaging Information
Shipping (Package) Weight: 26 g [0.9 oz]
Package Width: 12.5 cm [4.9 in]
Package Length: 22.5 cm [8.9 in]
Package Height: 16 mm [0.6 in]

Ports: 1
Chipset ID: PERICOM - PI3DPX1203
NXP - PTN5100
AV Output: DisplayPort - 1.4
AV Input: USB-C

Storage Temperature: -10°C to 70°C (14°F to 158°F)
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10%-85% RH

Connector B: DisplayPort (20 pin) Output Female
Connector A: USB-C (24 pin) DisplayPort Alt Mode Input Male

Model # CDP2DP
Barcode # 065030862622
Shipping Weight 0.0300kg
Shipping Width 0.230m
Shipping Height 0.020m
Shipping Length 0.130m
Shipping Cubic 0.000598000m3
Type AV Adapter/Converter
