HDMI 4X4 18G MATRIX HDCP2.2 SPDIF RS232

HDMI 4X4 18G Matrix

Features:

• HDMI 2.0 version (Support 4K@60Hz YUV4:4:4)
• Bandwidth upto 18Gbps
• HDCP2.2 input ,HDCP2.2 output
• HDCP1.4 input, HDCP1.4 output
• Support HDR10
• 4xHDMI Input, 4xHDMI output with 4xSPDIF Audio
• Any one of the 4 Ultra HD sources to any one of the 4Ultra HD displays
• Support Panel Button, Local IR, RS232 Control with command, IP Control, Web GUI Control
• Support Dolby True HD and DTS-HD master audio, Dolby Atmos under copy EDID mode
• Support firmware updating through USB port
• Unit size: L216XW105XH34mm

Specifications:

• Operating Temperature: 23°F to 113°F (-5°C to 45°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Resolution: 480p@60hz,576P@50hz,720P@60hz,1080P@24hz,1080P@50hz,1080P@60hz,4K@24hz,4K@30hz,4K@60hz YUV4:2:0, 4K@ 60hz YUV4:4:4
• HDCP Compliant: HDCP2.2 and HDCP1.4
• Output: Video HDMI2.0 and HDMI 1.4
• Audio Format: Supported PCM, Dolby5.1/7.1, DTS5.1/7.1 digital audio, Dolby Atmos
• RS-232 serial port: 3PIN terminal block connectors
• Ethernet port: (IP control) RJ45, female
• IR Ext port: 1x3.5mm stereo jack
• USB port: Micro 5P female
• Bandwidth: 18 Gbps
• Default IP: 192.168.1.168
• Rack-Mountable Rack ears included
• Dimensions(WxHxD): L216XW105XH34mm
• Net Weight: 0.72kg
• Power consumption:13W(Max)
