Star Tech IDE 40-pin to SATA Adapter Converter w/ HDD/SSD/ODD Support

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Star Tech IDE 40-pin to SATA Adapter Converter w/ HDD/SSD/ODD Support

The IDE2SAT2 40-pin IDE to SATA adapter enables you to connect a SATA I/II/III drive to an available IDE/ATA 33/66/100/133 motherboard port - a cost effective solution that allows you to add newer SATA drives, and keep your existing motherboard.

The IDE/SATA adapter offers a cost-effective solution for bridging the gap between a newer 2.5"/3.5"/5.25" SATA drive and older IDE motherboard port. The IDE2SAT2 also features ODD (Optical Disk Drive) support, allowing you to a add Blu-ray, DVD, or CD-ROM drives to an older IDE motherboard.

(IDE2SAT2)

This item comes with a 2 Years warranty

The IDE2SAT2 also features ODD (Optical Disk Drive) support, allowing you to a add Blu-ray, DVD, orCD-ROM drives to an older IDE motherboard.

Performance
Hardware Raid Supported  : No
Maximum Data Transfer Rate  : 133MB/sec

Physical Characteristics
Material  : Steel
Product Height  : 2.3 cm [0.9 in]
Product Length  : 75.5 mm [3 in]
Product Width  : 20 mm [0.8 in]
Weight of Product  : 29 g [1 oz]

Prominence
Description CDW 75 - 1st Line  : StarTech.com IDE to SATA Drive Adapter - 40-Pin PATA to 2.5" SATA HDD/ODD

Software
OS Compatibility  : OS independent; No software or drivers required

Special Notes / Requirements
System and Cable Requirements  : An IDE controller and ATA cable (not included).

What's in the Box
Included in Package  : IDE to SATA adapter
Instruction Manual
LP4 Molex to SP4 Power Cable

Packaging Information
Shipping (Package) Weight  : 89 g [3.1 oz]
Package Width  : 17.5 cm [6.9 in]
Package Length  : 14.5 cm [5.7 in]
Package Height  : 33 mm [1.3 in]

Hardware
Number of Drives  : 1
Interface  : IDE
Drive Size  : 2.5in & 3.5in
Compatible Drive Types  : SATA
Chipset ID  : Marvell - 88SA8052

Environmental
Storage Temperature  : -25°C to 80°C (-13°F to 176°F)
Operating Temperature  : 5°C to 50°C (40°F to 122°F)
Humidity  : 15~90% RH

Connector(s)
Connector Type(s)  : SP4 (4 pin, Small Drive Power)
SATA Data & Power Combo (7+15 pin)
IDE (40 Pin, EIDE/PATA)

Model # IDE2SAT2
Barcode # 065030852258
Brand STAR TECH
Shipping Weight 0.0900kg
Shipping Width 0.150m
Shipping Height 0.030m
Shipping Length 0.180m
Shipping Cubic 0.000837000m3
Type Adapter
