HDMI Over CAT6 Extender - POC - 4K at 70m - 1080p at 100m

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

This HDMI Over CAT6 extender transmits your HDMI audio/video signal to a remote location up to 100 m (328 ft.) away.

Get 4K at 60Hz from 70 m (230 ft.) away

This HDMI over CAT6 extender maintains your Ultra HD 4K picture quality, even at 70 m (230 ft.) away from your video source. If you're not running 4K video, this extender supports High-Definition 1080p 60Hz and lower resolutions at even greater distances, up to 100 m (328 ft.) from your HDMI source.

With full support for your HDMI 2.0 equipment, including 4K resolution at 60Hz, this extender can transmit at a bandwidth of up to 18Gbps, making it the ideal solution for high-resolution tasks requiring the highest color detail. For smoother video and color transitions, the extender offers 4:4:4 chroma subsampling via visually lossless compression, meaning every pixel gets its own unique color.

Simplify your setup

The HDMI Extender Over CAT6 offers a hassle-free solution for your digital signage project. The extender only requires a single CAT5e or CAT6 cable, so you extend an HDMI signal using existing infrastructure that’s already in your building. Plus, this HDMI extender supports Power Over Cable (POC), which means you’ll only need one power adapter connected to either your transmitter or receiver. Mounting hardware is also included for discreet, professional installation.

(ST121HDBT20L)

Standard Consumer Warranty

Packaging Information
Package Width: 20.6 cm [8.1 in]
Shipping (Package) Weight: 0.2 kg [0.5 lb]

Performance
Audio Specifications: 7.1 Surround Sound
Max Distance: 100 m / 330 ft
Maximum Cable Length: 100.1 m [328.4 ft]
Maximum Digital Resolutions: Up to 70 m: 4096 x 2160 (4K) @ 60 Hz
Up to 100 m: 1080p @ 60Hz
Supported Resolutions: 3840x2160 (4K) @ 60 Hz
2560x1600
1920x1200 @ 60 Hz
1920x1080 (1080p)
1280x720 (720p)
Wide Screen Supported: Yes

Physical Characteristics
Color: Black
Material: Aluminum
Product Height: 2.6 cm [1 in]
Product Length: 10.2 cm [4 in]
Product Width: 76 mm [3 in]
Weight of Product: 110 g [3.9 oz]

Power
Center Tip Polarity: Positive
Input Current: 0.6A
Input Voltage: 100 - 240 AC
Output Current: 1 A
Output Voltage: 18 DC
Plug Type: M
Power Consumption (In Watts): 18
Power Source: AC Adapter Included

What's in the Box
Included in Package: HDMI over CAT6 receiver : HDMI over CAT6 transmitter : IR blaster : IR receiver : mounting brackets : quick-start guide : rubber feet : universal power adapter (NA/JP, EU, UK, ANZ)

Packaging Information
Package Length: 28 cm [11 in]
Package Height: 62 mm [2.4 in]

Indicators
LED Indicators: status LED (remote) : status LED (local)

Hardware
Ports: 1
Daisy-Chain: No
Cabling: Cat 5e UTP or better
Audio: Yes

Environmental
Storage Temperature: -10°C to 60°C (14°F to 140°F)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 0% - 80 % RH (non-condensing)

Connector(s)
Remote Unit Connectors: RJ-45 Input Female : HDMI (19 pin) Output Female
Local Unit Connectors: RJ-45 Output Female : HDMI (19 pin) Input Female

Model # ST121HDBT20L
Barcode # 065030877879
Brand STAR TECH
Shipping Weight 0.2300kg
Shipping Width 0.280m
Shipping Height 0.060m
Shipping Length 0.210m
Shipping Cubic 0.003528000m3
Type HDMI Extender
