Celestion T5762: 1" 20W HF Driver 8OHM

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

The Celestion 1" 20W HF Driver 8OHM exit lightweight and compact ferrite magnet compression driver with 1.4" copper clad aluminium voice coil.

20Wrms power handling (AES standard) and 106dB sensitivity.

One piece PETP diaphragm and surround Finite Element Analysis (FEA) techniques used to optimise both magnetic and acoustic design.

Suitable for 2-way and 3-way systems.

Features:

  • Power rating 20Wrms

  • Sensitivity 106dB

  • Recommended min. crossover (12dB/oct) 2200Hz

  • Voice coil diameter 35mm/1.4in

  • Voice coil material Copper clad aluminium

  • Diaphragm material PETP film

  • Overall width 90mm/3.54in

  • Overall depth 52mm/2.05in

  • Unit weight 1kg/2.2lb

  • Fitting Flange (4 x M6 holes on 76mm/3in PCD)

  • Throat exit 25mm/1in

Includes:

  • 1x Celestion 1" 20W HF Driver 8OHM

(28-CDX1-1445)

Standard Consumer Warranty
One piece PETP diaphragm and surround Finite Element Analysis (FEA) techniques used to optimise both magnetic and acoustic design.

  • Colour: Black

  • Power Rating: 20W

Model # 28/CDX1-1445
Barcode # 739894576246
Brand CELESTION
Shipping Weight 1.0000kg
Shipping Width 0.090m
Shipping Height 0.080m
Shipping Length 0.090m
Shipping Cubic 0.000648000m3
Type High-Frequency Driver
