USB-C Multiport Adapter - HDMI & VGA - Mac/Windows - SD - PD

This item comes with a 36 months warranty

Power through your workday, withthree USB 3.0 (Type-A) ports with Fast-Charge support,SD™ and microSD™ card slots, and a Gigabit Ethernet port.

Hardware
Fast-Charge Port(s): Yes
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1

Packaging Information
Package Height: 30 mm [1.2 in]
Package Length: 14.2 cm [5.6 in]
Package Width: 17 cm [6.7 in]
Shipping (Package) Weight: 137 g [4.8 oz]

Performance
Audio Specifications: The HDMI port supports audio output
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
General Specifications: Each one of the three USB 3.0 (Type A) ports is also a fast-charge and sync port to charge your tablet or smartphone. Only one fast-charge port can be used at a time. : Each USB 3.0 port provides up to 7.5W of charging power, with a combined total of 10W when all 3 ports are in use. The charge provided depends on the number of devices connected and the amount of current each device draws. : Supports Fast Role Swap of PD 3.0, to ensure the connected devices will not be disconnected when your power adapter is disconnected from the multiport adapter. : With support for USB Power Delivery 3.0, the multiport adapter will power and charge your laptop, and power your peripherals at the same time, providing up to 85W of charging power, when using a 100W power adapter. Charging power will be less when using a lower-wattage power adapter.

Maximum Analog Resolutions: 1920 x 1200p @ 60Hz (VGA)
Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 3840 x 2160p (HDMI) @ 30Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p

Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes

Physical Characteristics
Cable Length: 118 mm [4.6 in]
Color: Black
Material: Plastic
Product Height: 1.4 cm [0.6 in]
Product Length: 12.2 cm [4.8 in]
Product Width: 70 mm [2.8 in]
Weight of Product: 129 g [4.6 oz]

Power
Power Source: USB-Powered

Prominence
Description CDW 75 - 1st Line: StarTech.com USB C Multiport Adapter 4K HDMI/VGA - PD 3.0/3xUSB/SD/MicroSD

Software
OS Compatibility: Windows® 7, 8, 8.1, 10
macOS 10.11 to 10.15, 11.0
Chrome OS™

Special Notes / Requirements
Note: A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K) : Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 3.0 and DP Alt Mode. : The adapter can connect to a host laptop’s USB-C port that doesn’t support USB Power Delivery 3.0. However, if your laptop’s USB-C port supports USB Power Delivery 2.0, it will still support PD pass-through, but it will not support Fast Role Swap. If you laptop's USB-C port does not support Power Delivery, then it will not support PD pass-through. : USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps.

Hardware
Displays Supported: 1
Chipset ID: VIA/VLI - VL102
VIA/VLI - VL817
Parade - PS8338B
Parade - PS176
Analogix - ANX9833
ALCOR MICRO - AU84612
Realtek - RTL8153
Bus Type: USB-C
4K Support: Yes

Environmental
Storage Temperature: -10°C to 70°C (14°F to 158°F)
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10%-85%RH

Connector(s)
Connector Type(s): VGA (15 pin, High Density D-Sub) Female: USB-C (24 pin) USB Power Delivery only Female: USB Type-C (24 pin) USB 3.0 (5Gbps) Male: USB 3.0 A (Fast-Charge, 9 pin) Female: SD / MMC Slot Female: RJ-45 Female: MicroSD Female: HDMI (19 pin) Female

Special Notes / Requirements
Note: Your laptop might have specific charging requirements. The USB-C adapter supports USB Power Delivery 3.0 to provide up to 85W of charging power, when using a 100W power adapter. Charging power will be less when using a lower-wattage power adapter.
System and Cable Requirements: A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 3.0 and DP Alt Mode) : USB-C power adapter (for example, your laptop’s USB-C based power adapter)

What's in the Box
Included in Package: multiport adapter : User manual
