Star Tech 2 Port PCIe USB 3.1 Card - 2x USB C - Up to 10Gbps

This PCIe USB 3.1 Gen 2 card installs into an available PCI-Express slot in your computer and enables you to upgrade your current system by adding two USB-C™ (10Gbps) ports.

Faster USB Performance

Also known as USB 3.2 Gen 2x1, this USB 3.1 Gen 2 card adds two 10Gbps USB Type-C™ ports to your computer.

Utilizing an ASMedia ASM3142 chipset, this card harnesses the speed of USB 3.1 Gen 2. With higher data throughput support, this USB 3.1 Gen 2 PCIe expansion card is a necessity for external drives and many other USB 3.1 Gen 2 peripherals and includes an optional SATA power connector for high power devices.

The card is backward compatible with USB 3.0 (5Gbps) and USB 2.0 (480mbps) devices. The card works with newer USB-C devices, but can easily support your existing USB-A peripherals using inexpensive USB Type C cables and adapters. See our Accessories Tab for supported options.

Easy Installation

The USB 3.1 card is compatible with Windows®, Linux® and macOS® operating systems. The card includes both standard-profile and low-profile brackets to install in various form-factor PCs and servers.

The Choice of IT Pros Since 1985

StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.

(PEXUSB312C3)

This item comes with a 2 Years warranty

Also known as USB 3.2 Gen 2x1, this USB 3.1 Gen 2 card adds two 10GbpsUSB Type-C™ports to your computer.

Packaging Information
Package Width  : 14.2 cm [5.6 in]
Shipping (Package) Weight  : 120 g [4.2 oz]

Performance
Maximum Data Transfer Rate  : 10Gbps
Type and Rate  : USB 3.2 Gen 2 - 10 Gbit/s
UASP Support  : Yes

Physical Characteristics
Material  : Steel
Product Height  : 1.8 cm [0.7 in]
Product Length  : 12.2 cm [4.8 in]
Product Width  : 8 cm [3.1 in]
Weight of Product  : 0 kg [0.1 lb]

Prominence
Description CDW 75 - 1st Line  : StarTech.com 2-port 10Gbps USB C PCIe Card - USB 3.1 Gen 2 PCI Express Card

Software
OS Compatibility  : Windows® 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012 R2, 2016, 2019
Linux® 3.5 to 4.11.x LTS version only
macOS Catalina (10.15)
macOS Mojave (10.14)
macOS High Sierra (10.13) macOS Big Sur (11.0)

Special Notes / Requirements
Note  : The card's USB-C ports are standard data throughput port. They do not support DP Alt Mode or USB Power Delivery.
The maximum throughput of this card is limited by the bus interface. PCI Express Gen 1.0 max throughput is 2.5Gbps. PCI Express Gen 2.0 max throughput is 5Gbps. PCI Express Gen 3.0 max throughput is 10Gbps.
System and Cable Requirements  : Optional SATA power connector
PCI Express enabled computer or server with a PCI Express x4 slot or higher (x8, x16)

What's in the Box
Included in Package  : Low Profile Bracket
Quick Start Guide
USB 3.1 Card

Packaging Information
Package Length  : 17.3 cm [6.8 in]
Package Height  : 3 cm [1.2 in]

Hardware
Ports  : 2
Port Style  : Integrated on Card
Interface  : USB 3.1 Gen 2
Industry Standards  : USB 3.2 Specification Rev. 2.0
USB Specification Rev. 2.0
PCI Express Base Specification Rev. 3.0
Intel xHCI Specification Rev. 1.1
UASP (USB Attached SCSI Protocol) Rev. 1.0
Chipset ID  : ASMedia - ASM3142
Card Type  : Standard Profile (LP bracket incl.)
Bus Type  : PCI Express

Environmental
Storage Temperature  : -20°C to 85°C (-4°F to 185°F)
Operating Temperature  : 0°C to 70°C (32°F to 158°F)
Humidity  : 20~80% RH

Connector(s)
Internal Ports  : SATA Power (15 pin) Plug
External Ports  : USB Type-C (24 pin) USB 3.1 (10Gbps) Female
Connector Type(s)  : PCI Express x4 Male

Model # PEXUSB312C3
Barcode # 065030887434
Brand STAR TECH
Shipping Weight 0.1200kg
Shipping Width 0.170m
Shipping Height 0.030m
Shipping Length 0.140m
Shipping Cubic 0.000737000m3
Type USB Card Adapter
