Star Tech 7 Pt PCIe USB 3.0 Adapter Card - SATA Power - UASP Support

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Star Tech 7 Pt PCIe USB 3.0 Adapter Card - SATA Power - UASP Support

Handle your workload more efficiently. This USB 3.0 card expands your computer’s capabilities by giving you seven extra USB 3.0 ports. It’s engineered with an innovative stacked port layout to fit easily into both low-profile and standard desktop computers.

Greater port count. Greater scalability.

More ports means you can add USB devices as you need them.  This robust USB 3.0 card gives you seven USB 3.0 ports - six external and one internal - so you can plug in your tablets, smartphones, external hard drives, CD/DVD drives, printer and other devices at the same time. With so many extra ports, you can leave your devices plugged in, so they’re ready to use when you need them. It’s also economical - by being able to connect so many devices, you save the cost of extra hubs or cards.

The internal USB 3.0 port lets you connect a USB device inside your computer for added convenience and security.

Unique dual-profile design

This versatile USB 3.0 card features a dual-profile design with a stacked port layout. The innovative port configuration allows a high number of external ports in a compact design, allowing it to fit both low-profile and full desktop computer systems. A bracket is included for installation into low-profile computers.

Easy driver installation

You'll be up and running in no time. The card automatically installs in Windows® 8.1 or later, with native operating system support. It’s also backward compatible with USB 2.0 and 1.x devices to help you get the most out of your existing peripherals.

Effective USB 3.0 performance enhanced by UASP

This high-performance SuperSpeed USB 3.0 card supports data transfer rates up to 5 Gbps and is enhanced with UASP support, which can perform ~70% faster read speed and 40% faster write speed over traditional USB 3.0, when paired with a UASP-enabled enclosure.

The rugged build quality of the card delivers long-lasting performance, and gives you peace of mind when connecting multiple devices.

(PEXUSB3S7)

This item comes with a 2 Years warranty

It’s engineered withan innovativestacked port layouttofit easily into bothlow-profile and standard desktop computers.

Packaging Information
Package Length  : 17.6 cm [6.9 in]
Package Width  : 14.3 cm [5.6 in]
Shipping (Package) Weight  : 150 g [5.3 oz]

Performance
Maximum Cable Length  : 3 m [9.8 ft]
Maximum Data Transfer Rate  : 5 Gbps
MTBF  : 1,920,042 Hours
Type and Rate  : USB 3.0 - 5 Gbit/s
UASP Support  : Yes

Physical Characteristics
Material  : Steel
Product Height  : 12 cm [4.7 in]
Product Length  : 10.5 cm [4.1 in]
Product Width  : 15 mm [0.6 in]
Weight of Product  : 72 g [2.5 oz]

Software
OS Compatibility  : Windows® XP, Vista, 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
Linux 2.6.31 to 4.11.x LTS Versions only

Special Notes / Requirements
Note  : The maximum throughput of this card is limited by the bus interface. If used with PCI Express Gen 1.0 enabled computers, the max throughput is 2.5 Gbps. If used with PCI Express Gen 2.0 enabled computers, the max throughput is 5 Gbps.
System and Cable Requirements  : PCI Express enabled computer or server with an available PCI Express x1 slot or higher (x4, x8, x16)
SATA power connector (recommended, but optional)

What's in the Box
Included in Package  : 7 Port PCI Express USB 3.0 Card
Driver CD
Instruction Manual
Low-Profile Bracket

Packaging Information
Package Height  : 32 mm [1.3 in]

Hardware
Ports  : 7
Port Style  : Integrated on Card
Interface  : USB 3.0
Industry Standards  : USB 3.0 Specification Rev. 1.0
PCI Express Base Specification Rev. 2.0
Intel xHCI Specification Rev. 1.0
Chipset ID  : Renesas/NEC - µPD720201
µPD720210
Card Type  : Standard Profile (LP bracket incl.)
Bus Type  : PCI Express

Environmental
Storage Temperature  : -25°C to 70°C (-13°F to 158°F)
Operating Temperature  : 5°C to 50°C (41°F to 122°F)
Humidity  : 20~80% RH

Connector(s)
Internal Ports  : USB Type-A (9 pin) USB 3.0 (5 Gbps) Female
SATA Power (15 pin) Plug
External Ports  : USB Type-A (9 pin) USB 3.0 (5 Gbps) Female
Connector Type(s)  : PCI Express x1 Male

Model # PEXUSB3S7
Barcode # 065030860345
Brand STAR TECH
Shipping Weight 0.1500kg
Shipping Width 0.180m
Shipping Height 0.030m
Shipping Length 0.140m
Shipping Cubic 0.000805000m3
Type USB Card Adapter
