1U 8 Port VGA Rackmount KVM Console for Server Racks - 17in

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

1U 8 Port VGA Rackmount KVM Console for Server Racks - 17in

Providing centralized control of up to eight servers, this 8-port rackmount KVM console gives you easy access to your systems. With a minimal footprint, it mounts in a server rack or cabinet using only 1U of rack space.

An All-Inclusive Solution 

The 1U rackmount console features a built-in keyboard, a touchpad for intuitive control, and a 17-inch LCD display that supports resolutions up to 1280x1024.

This 8-port KVM console comes with everything you need to set up right out of the box: 

  • 8 VGA KVM Cables
  • Mounting Rails
  • M5 Cage Nuts and Screws

Simple System Integration


With direct access to eight systems or servers, the 8-port KVM module gives you the flexibility you need to easily integrate the console into your existing server infrastructure.

StarTech.com Rack Consoles

Rack consoles provide convenient, rack-mounted control options for single servers or the entire server room. KVM consoles include LCD display, keyboard, and trackpad, all sliding into 1U of rack space.

(RKCONS1708K)

This item comes with a 24 months warranty

Hardware
PC Interface: USB
PC Video Type: VGA
Rack-Mountable: Yes
U Height: 1U

Indicators
LED Indicators: Green/Red - Online/Selected LED

Packaging Information
Package Height: 18.2 cm [7.2 in]
Package Length: 61.7 cm [24.3 in]
Package Width: 7.6 cm [3 in]
Shipping (Package) Weight: 19.7 kg [43.5 lb]

Performance
Aspect Ratio: 5:4
Brightness: 250 cd/m²
Color Depth: 8-bit, 16.7M colors
Contrast Ratio: 1000:1
IP Control: No
Maximum Analog Resolutions: 1280 x 1024
Maximum Number of Users: 1
MTBF: 50, 000 Hrs
On-Screen Display: Yes
Pixel Pitch Support: 0.264 x 0.264 mm
Port Selection Support: Push Button, Hotkeys, and OSD (On Screen Display)
Response Time: 5ms
Supported Resolutions: Resolutions up to 1280 x 1024 @ 60Hz
Viewing Angle: 170° (H), 160° (V)

Physical Characteristics
Cable Length: 6 ft
Color: Black
Material: Steel
Maximum Mounting Depth: 90 cm [35.4 in]
Minimum Mounting Depth: 56 cm [22 in]
Product Height: 4.2 cm [1.7 in]
Product Length: 62.3 cm [24.5 in]
Product Width: 4.8 cm [1.9 in]
Weight of Product: 128.8 kg [284.7 lb]

Power
Input Current: 1.5A

Hardware
Panel Type: Active Matrix TFT LCD
Number of Monitors Supported: 1
KVM Ports: 8
Front Door Key Lock: No
Display Size: 17in
Daisy-Chain: No
Cables Included: Yes
Audio: No

Environmental
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10 ~ 80% RH

Connector(s)
Other Interface(s): 15 Pin High Density D-Sub Input Female
Host Connectors: VGA (15 pin, High Density D-Sub) Input Female
Console Interface(s): VGA (15 pin, High Density D-Sub) Output Female : USB Type-A (4 pin) USB 2.0 Input Female

Power
Input Voltage: 100 - 240 AC
Power Consumption (In Watts): 17W
Power Source: International Power Cords

Prominence
Description CDW 75 - 1st Line: StarTech.com 8 Port Rackmount KVM Console w/ Cables KVM Switch w/ 17" LCD

Special Notes / Requirements
Note: The minimum mounting depth of this rackmount console is less than the length of the console itself. Please consider the length of the rackmount console when evaluating if it will fit into your rack.

What's in the Box
Included in Package: KVM cables : KVM console : M5 cage nuts : M5 screws : Mounting Rails : Power Cords (NA, JP, UK, EU, ANZ) : Quick-Start Guide

Model # RKCONS1708K
Barcode # 065030872485
Brand STAR TECH
Shipping Weight 19.6700kg
Shipping Width 0.620m
Shipping Height 0.180m
Shipping Length 0.080m
Shipping Cubic 0.008534000m3
Type KVM Switch Box
