KVM Switch - 4K60 - 4 Port

This 4-port dual DP KVM switch combines dual 4K 60Hz displays with KVM switch control of four connected PC and Mac computers. It features audio and USB peripheral support along with dual-display capability, which makes it easy to create a multimedia workstation that can switch between two dual-head DP systems.

Maximize productivity with dual video

With two DP video inputs and control of four different computers, this Ultra HD KVM switch helps maximize productivity by giving you the freedom to multitask. Each of the DP ports supports resolutions up to 4K 60Hz, for maximum screen viewing space.

Astonishing picture quality

The dual DisplayPort KVM switch supports resolutions up to 4K at 60Hz, and can drive two large DP displays with ease. An ideal solution for creating workstations where high-quality imaging is critical, such as for graphic design.

Convenient multimedia and peripheral sharing

The KVM switch features full multimedia control with separate 3.5 mm microphone and speaker ports and two USB ports separate from the HID keyboard and mouse. The independent audio support lets you share independent analog audio from each of your connected computers, while the 2-port USB hub enables you to share USB peripherals between each connected computer.

(SV431DPDDUA2)

This item comes with a 24 months warranty

Maximize productivity with dual video

Hardware
PC Interface: USB
PC Video Type: DisplayPort
Rack-Mountable: Optional
U Height: 2U

Indicators
LED Indicators: Green - Online indicator (One LED per port) : Power : Red - Select indicator (One LED per port)

Packaging Information
Package Height: 87 mm [3.4 in]
Package Length: 29.7 cm [11.7 in]
Package Width: 24.3 cm [9.6 in]
Shipping (Package) Weight: 1.8 kg [3.9 lb]

Performance
Aspect Ratio: 16:9
Auto Scan: 3, 8, 15 & 30 seconds
DVI Support: No
Hot-Key Selection: Yes
IP Control: No
Maximum Data Transfer Rate: 500 Mbps (USB 2.0)
Maximum Digital Resolutions: 3840 x 2160 (Ultra HD 4K) @ 60hz
Maximum Number of Users: 1
MTBF: 142000 hours
On-Screen Display: No
Port Selection Support: Push Button and Hotkeys
Supported Resolutions: 1024x768
1280x720 (High-definition 720p)
1920x1080 (High-definition 1080p)
1920x1200
2560x1600
3840 x 2160 (4K)@ 60hz
Wide Screen Supported: Yes

Physical Characteristics
Color: Black
Material: Steel
Product Height: 6.3 cm [2.5 in]
Product Length: 12.7 cm [5 in]
Product Width: 21.6 cm [8.5 in]
Weight of Product: 1.2 kg [2.7 lb]

Power
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 - 240 AC

Hardware
Number of Monitors Supported: 2
KVM Ports: 4
Daisy-Chain: No
Cables Included: No
Audio: Yes

Environmental
Storage Temperature: -10℃ - 60℃
Operating Temperature: 0℃ - 40℃
Humidity: 0% - 80%

Connector(s)
Host Connectors: USB B (4 pin) Female : DisplayPort (20 pin) Female : 3.5 mm Mini-Jack (3 Position) Female
Console Interface(s): USB Type-A (4 pin; HID Port) USB 1.1 Female: USB Type-A (4 pin) USB 2.0 Female : DisplayPort (20 pin) Female : 3.5 mm Mini-Jack (3 Position) Female

Power
Output Current: 1.5 A
Output Voltage: 12V DC
Plug Type: M
Power Consumption (In Watts): 18 W
Power Source: AC Adapter Included

Prominence
Description CDW 75 - 1st Line: StarTech.com 4 Port Dual DisplayPort KVM Switch - DP KVM Switch - 4K (60Hz)

What's in the Box
Included in Package: KVM switch : quick start guide : rubber feet : universal power adapter (NA/JP, EU, UK, ANZ)

Model # SV431DPDDUA2
Barcode # 065030867863
Brand STAR TECH
Shipping Weight 1.7500kg
Shipping Width 0.300m
Shipping Height 0.090m
Shipping Length 0.240m
Shipping Cubic 0.006279000m3
Type KVM Switch Box
